Assembly

Quality Assurance

1x 3D Koordinatenmessmaschine Mitutoyo Crysta Apex C

Year of construction 2008
Measurement x / y / z 500x400x400mm

1x 3D Koordinatenmessmaschine Mitutoyo Euro M544

Year of construction 2000
Measurement area x / y / z 500x400x400m

1x Optacom LC 10

Year of construction 2012
Measurement area x / z 225x225mm

1x Keyence IM6120

Year of constructions 2014
Measurement are x / z 100mmx200mm

1x Wellenmessmaschine ViciVision M309 Techno

Year of construction 2017
Measurement Ø90 / z 300mm

1x Kleinlast Härteprüfgerät Zwick 3202

Testing height + outreach 0 - 300/135 mm

1x Zoom Stereomikroscope Motic 2011

Magnification 10X-40X

1x Endoskop Endoscan 2017

Ø 2.00 0° + 90° 100 - 200 mm

1x Aicon Tube Inspect 3D Messzelle 2009

16 cameras 1° - 180°
Ø 4,00 - 200mm
Single measurement area 2500x1000x700mm
Multiple measurements 10x

1x Beschritungslaser DPL-Magic Marker 2000

Laser area x / y 110x110mm

1x Conturograph CV200 2005

Measurement area x / z 225x225mm

Machinery

2X Mazak Nexus 100 M

Compact truning machine with milling function
12 tool places ; toolholder VDI
Max. machining diameter 220 mm
Max. bar diameter 40 mm
Chuck diameter 6" ; max. revolution 6000 min/1

9x Mazak Nexus 100 MSY

High performance machine with powered tooling "Y" axis and handover spindle
16 tool places VDI (powered tooling usable on all stations)
Max. machining diameter 280 mm
Chuck diameter main spindle/counter spindle 6" / 5"
Max. bar diameter 51 mm
Traveling distance x / y / z 180x100x455 mm

1x Mazak Nexus 200 MSY

Year of construction 2007
High performance machine with powered tooling "Y" axis und handover spindle
16 tool places VDI (powered tools usable on all stations)
Max. machining diameter 380 mm
Chuck diameter main spindle/counter spindle 8" / 6"
Max. bar diameter 65 mm
Traveling distance x / y / z 230x100x575mm

1x Mazak Integrex III ST

Year of construction 2005
Turning and milling center with handover spindle and lower revolver
Single spindle revolver for fixed or powered tools with B-axis
Tooling changer with 40 WZ, lower revolver mit 9 WZ
"C " axis indexing from 0° - 360° in 0,001° steps
Max. turning diameter 450 mm
Max. bar diameter 51 mm
Traveling distance x / y / z / w 410x140x570x795mm
B axis from -30° to +195°
5 axis simultaneous machining

1x Mazak Integrex IV ST

Year of construction 2007
Milling and turning center with handover spindle and lower revolver
One spindle revolver for fixed or powered tooling with B axis
Tool changer with 40 WZ, lower revolver with 9 WZ
"C " axis indexing from 0° - 360° in 0,001° steps
Max. turning diameter 545 mm
Max. bar diameter 51 mm
Traveling distance x / y / z / w 410x140x805x795mm
B axis from -30° to +195°
5 axis simultaneous machining

1x Mazak Integrex i100 S

Year of construction 2016
Multi-functional-machiningcenter
Mazatrol " SmoothX " controls
Single spindle revolver for fixed or powered tooling with B axis
Tooling changer with 72 WZ Capto C6 uptake
"C " axis indexing from 0° - 360° in 0,001° steps
Max. turning diameter 545mm
Max. bar diameter 65mm
Traveling distance x / y / z / w 450x210x904x903mm
B axis from -30° to +195°
5 axis simultaneous machining

1x Mazak Hyper Quadrex 150 MSY

Year of construction 2008
High performance machine with powered tooling "Y" axis and handover spindle and lower revolver
Revolver with 12 (upper) and 12 (lower) tooling places (powered toolings on all stations useable)
Max. machining diameter 380mm
Chuck diameter main spindle/counter spindle 8" / 6"
Max. bar diameter 65mm
Traveling distance x / y / z 230x100x575mm

1x Mazak QTN-10

CNC turning machine
Max. machining diameter 220mm
12 tooling places
Chuck diameter 6"
Tail stock

1x Mazak NEXUS 100 MY

Year of construction 2012
High performance machine with powered tooling "Y" axis and tail stock
12 tooling places; tooling holder VDI
Max. machining diameter 280mm
Max. bar diameter 40mm
Chuck diameter 6"; max. revolutions per minute 6000min/1
Traveling distance x / y / z 185x100x385mm

1x Mikron UCP 600 Vario

Year of construction 2008
5 axis machining center
Controls - Heidenhain iTNC 530
"C" axis 360°, "B" axis -115° / +30°
3R - Dynafix rotary tilting table
7-fold pallet exchanger 3R Dynafix 280x280
Laser tool measurement
Traveling distance x / y / z 600x450x450mm

4x Hurco VMX 30 -Ui

Year of construction 2010-2016
5 axis CNC machining center
Traveling distance x / y / z 760x510x520mm
"C" axis 360° , "A" axis from -30° to + 110°

1x Hurco VMX 40

Year of construction 2001
3 axis CNC milling center
Traveling distance x / y / z 760x460x610mm

1x Hurco BMC 30

Year of construction 1989
3 axis CNC milling machine
Traveling distance x / y / z 760x460x610mm

1x Kasto-Bandsäge Verto A2

Year of construction 2012
Bandsaw automat
Automatic zero positioning
Cutting area 90° round 260mm
Cutting area sheet 320x260mm
